Descripción
Display
Aspect Ratio | 16×10 | Native Resolution | WXGA 1280×800 |
Maximum Resolution | Up to 4K@30 (HDMI), WUXGA (1920×1200) Analog | Contrast Ratio (typical) | 3,000,000:1 (with Dynamic Contrast) |
Synchronization Range
Horizontal (Analog/Digital) | 15-100kHz (RGB: 24kHz or over) | Vertical | 24-85Hz |
Signal Compatibility/Connectivity
SD/HD Video Signal Compatibility | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 4K UHD | PC Signal Compatibility | VGA, SVGA, XGA, SXGA, SXGA+, UXGA, WUXGA |
Macintosh Signal Compatibility | Yes | External Control | RS-232 (D-Sub 9pin), IR, LAN |
Input Terminals
RGB1(analog):
VGA 15-pin D-sub
RGB1(digital):
HDMI w/ HDCP (v1.4b)
RGB2(digital):
HDMI w/ HDCP (v1.4b)
Audio 1:
Stereo Mini Jack
|
Output Terminals
Audio:
Stero Mini Jack
Audio Out:
Stereo Mini Jack
Monitor Out:
VGA 15pin D-sub
|
Power Consumption (typical)
On | 330W / 212W / 187W / 2W / 0.5W | Input Current | 4.5-1.6A |
Power Requirements | 100-240V AC, 50/60 Hz |
Physical Specifications
Dimensions (WxHxD)
Product:
15.9 x 5.4 x 14.1 in. (405 x 137 x 358 mm)
Shipping:
20.1 x 10.2 x 19.7 in. (510 x 260 x 500 mm)
|
Weight
Net Weight:
17.3 lbs. (7.85 kg)
Shipping:
21.7 lbs. (9.85 kg)
|
Environmental Conditions
Operating Temperature | 32-104°F / 0-40°C | Operating Humidity | 20 to 88% Humidity (Non-Condensing) |
Storage Temperature | 14-122°F / -10-50°C | Storage Humidity | 20 to 80% Humidity (Non-Condensing) |
Limited Warranty (parts & labor)
Registered owners receive a 5-year parts and labor warranty including InstaCare next business day exchange. |
Additional Features
|
Optical
Display Technology | 0.64″ LCD | Light Output(Lumens) | 5,200 normal |
Light Source Life | 20,000 hours normal / 30,000 hours eco | Screen Size (diagonal) | 30 – 300 in. / 0.76 – 7.62m |
Throw Ratio | 1.2 – 2.1:1 | Projection Distance | 2.6 to 44.3 ft. / 0.8 to 13.5m |
Projector Angle | 0 – 9.6° tele / 0 – 15.9° wide (at 60″) | Lens
Zoom:
1.66x
Focus:
Manual
F number, fnumber:
F:1.7~2.21 /f=17.42~28.99mm
|
|
Keystone Correction | +/- 30° horizontal (manual), +/- 30° vertical (manual + auto) |
Mechanical
Installation Orientation | Floor/Front, Floor/Rear, Ceiling/Front, Ceiling/Rear | Fan Noise | 37dB (ECO mode Off), 27dB (ECO mode) |
Regulations | USA: UL (UL60950-1/UL62368-1) FCC Part15 Class B, Canada: CAN/CSA (62368-1-14) ICES-003 Issue 7 |
Accessories
Included |
|
Optional |
|
Lens Adjustment Functions
Manual focus, zoom, shift |
Supported Screen Size (maximum)
30 – 300 in. / 0.76 – 7.62m |
