Descripción
Display
Aspect Ratio | 16:10 (Supports | Native Resolution | WUXGA 1920×1200 |
Maximum Resolution | Up to 4K UHD (3840×2160) @ 30Hz via HDMI, HDBaseT, Up to WUXGA (1920×1200) via Analog | Contrast Ratio (typical) | 3,000,000:1 |
Synchronization Range
Horizontal (Analog/Digital) | 15-100kHz (RGB: 24kHz or over) | Vertical | 15-120Hz |
Signal Compatibility/Connectivity
SD/HD Video Signal Compatibility | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 4K UHD | PC Signal Compatibility | VGA, SVGA, XGA, WXGA, SXGA, WUXGA |
Macintosh Signal Compatibility | Yes | External Control | RS-232 (D-Sub 9pin), IR, LAN, HDBaseT |
Input Terminals
RGB1(analog):
VGA 15-pin D-sub
RGB1(digital):
HDMI w/ HDCP (v1.4)
RGB2(digital):
HDMI w/ HDCP (v1.4)
RGB3(digital):
HDBaseT w/ HDCP (v1.4)
Audio 1:
Stereo Mini Jack
|
Output Terminals
Audio Out:
Stereo Mini Jack (variable)
|
Power Consumption (typical)
On | 328W / 239W / 287W / 2W / 0.3W | Network Standby | 2W |
Power Savings Mode | 0.3 W | Input Current | 5.1-2.1A |
Power Requirements | 100-240V AC, 50/60 Hz |
Physical Specifications
Dimensions (WxHxD)
Product:
18.9 x 5.6 x 16.0 in. (480 x 142.5 x 407 mm)
Shipping:
23.3 x 10.2 x 19.3 in. (591 x 259 x 491 mm)
|
Weight
Net Weight:
20.7 lbs. (9.4 kg)
Shipping:
27.6 lbs. (12.5 kg)
|
Environmental Conditions
Operating Temperature | 32-104°F / 0-40°C | Operating Humidity | 20 to 80% Humidity (Non-Condensing) |
Operating Altitude | 0 to 2600 m (8,500 ft), 1600 m (5,500 ft | Storage Temperature | 14-122°F / -10-50°C |
Storage Humidity | 20 to 80% Humidity (Non-Condensing) | Storage Altitude | 0-12,000m / 0-39,370ft (above sea level) |
Limited Warranty (parts & labor)
Registered owners receive a 5-year or 20,000 hour parts and labor warranty including InstaCare next business day exchange. |
Additional Features
|
Optical
Display Technology | 0.64″ LCD w/ MLA | Lamp Type | Laser/Phosphor |
Light Output(Lumens) | 6,200 Lumens (Eco Off, 100%) | Light Source Life | 20,000 hours (until 50% brightness) |
Throw Ratio | 1.23-2.0:1 | Projection Distance | 2.6 to 42.3 ft. / 0.8 to 12.9m |
Projector Angle | 0 – 10.7° tele / 0 – 17.1° wide (at 100″) | Lens
Zoom:
1.6
Focus:
Manual
F number, fnumber:
F:1.5~2.1 /f=17.2~27.7mm
|
|
Keystone Correction | Manual (+/- 30° horizontal/vertical) |
Mechanical
Installation Orientation | Floor/Front, Floor/Rear, Ceiling/Front, Ceiling/Rear | Fan Noise | 27dB (ECO mode Off), 22dB (ECO mode) |
Regulations | USA: UL (UL60950-1 2nd ed. / UL62368-1 3rd ed.) FCC Part15 Class B, Canada: CAN/CSA (62368-1:19) ICES-003 Issue 7 |
Accessories
Included |
|
Optional |
|
Lens Adjustment Functions
Manual focus, zoom, shift |
Supported Screen Size (maximum)
30 – 300 in. / 0.76 – 7.62m |
