Descripción
| Color |
Black(Lead-Free Paint)
|
| Combined +3.3V & +5V |
120W
|
| Combined +12V |
744W
|
| Input Voltage |
90 ~ 264 Vrms
|
| Input Frequency Range |
47Hz ~ 63Hz
|
| PFC |
Active PFC(PF>0.96 at full load)
|
| Efficiency |
82% ~ 85% @ 20% ~ 100% loading
|
| MTBF |
100,000 hours
|
| Operating temperature |
0°C ~ 40°C
|
| Protection |
Over Current Protection
Over Power Protection Over Voltage Protection Short Circuit Protection Over Temperature Protection |
| Connectors |
1 x 24 / 20-Pin motherboard connector(500mm)
1 x 8 / 4-Pin EPS / ATX 12V connector(750mm) 4 x 8 / 6-Pin PCIE connector(»500mm / 150mm» x 2) 6 x SATA connector(»500mm / 150mm / 150mm» x 2) 3 x 4-Pin Peripheral connector(500mm / 150mm / 150mm) 1 x 4-Pin Floppy connector(500mm / 150mm / 150mm / 150mm) |
| Cooling System |
Single 120mm silent fan
|
| Form factor | ATX |
| Noise Level |
18dBA minimum
|
| Dimension |
150 mm (W) x 86 mm (H) x 140 mm (D)
5.91″ (W) x 3.39″ (H) x 5.51″ (D) |
